dB-Mark XCA26 PLUS V2 - 2-in 6-out Digital Active Crossover
2 input 6 output Pro Speaker Management System Controller

Product Code: DBMXCA26PLUS | Brand: dBMark
dB-Mark XCA26 PLUS V2 - 2-in 6-out Digital Active Crossover
£359.00
£299.17 ex VAT
Login to see JAM Club pricing
Not a member? Join Now
£8.22 DELIVERY to mainland UK.
dB-Mark XCA26 PLUS V2 - 2-in 6-out Digital Active Crossover

All XCA PLUS V2 models since July 2021 have ethernet connectivity with web based GUI, allowing you to control the settings from any Windows based device on the same network that supports a modern browser with javascript enabled.


  • 2 balanced inputs and 6 balanced outputs on XLRs.
  • XCA + Series offers superior audio quality with THD: <0.002% and SNR >108.8dB
  • All channels can be configured using Parametric EQ, High/Low Shelf EQ, and 1st/2nd order All Pass filters.
  • Fully adjustable crossover filters on all output channels, with slopes from 12dB to 48dB per octave.
  • Linkwitz-Riley, Butterworth, or Bessel curves can be individually selected on the high-pass and low-pass.
  • Each input has 2 dynamic EQs, noise gate, and adjustable compressor.
  • Automatic Gain Control available on input channels.
  • Configurable compressor and peak limiter on every output channel.
  • Delay on all channels, adjustable in milliseconds, metres or feet.
  • Full matrix mixing, route any input to any output.
  • All input and output channels can be individually muted.
  • Channels can be linked for convenience to allow editing of two or more channels at a time
  • 32-bit digital signal processor with 24-bit 96KHz A/D and D/A converters.
  • USB 2.0/3.0, RS485 connections are provided for PC control of multiple devices.
  • Operation possible using the front panel controls or via dedicated Windows app.
  • 30 user-program presets can be stored into the device and recalled, or backed-up to PC via USB.
  • Password protection for partial or full lock of system settings.
  • LED indicators on all input and output channels for level, mute, compressor, limiter, and peak/clip.
  • 2x24 character dot-matrix blue back-lit LCD display.
  • Gross weight: 5.25kg
  • Shipping Dimensions: 562mm x 325mm x 98mm
  • Power 110V /220V AC 50/60Hz <25W
  • DAC Chip: PCM1798
  • ADC Chip: AK5388
  • DSP Chip: Texas Instruments TM320C6726
  • Op Amps: MC33078,MC33079

Please click here to visit www.dbmark.co.uk downloads page for all relevant software



Detailed specifications unavailable, please EMAIL the sales office for additional information.
