Faital Pro 8HX150 8" 250W 8 Ohm

Nominal Specifications

Nom. Diameter - 200 mm (8 in)
Overall Diameter - 223.75/207.9 mm (8.81/8.18 in)
Bolt Circle Diameter - 210 mm (8.27 in)
Baffle Cutout Diameter - 183 mm (7.20 in)
Depth - 111.7 mm (4.40 in)
Flange and Gasket Thickness - 10.7 mm (0.42 in)
Net Weight - 3.6 Kg (7.9 lb)
Shipping Box (Single Carton Box) - 246 x 246 x 150 mm (9.7 x 9.7 x 5.9 in)
Shipping Weight - 4.3 Kg (9.5 lb)

Nom. Impedance	8 Ohm	8 Ohm
Minimum Impedance	6.6 Ohm	6.3 Ohm
AES Power Handling	250 W	15 W
Max Power Handling	500 W	30 W
Sensitivity (1W/1m)	94 dB	104 dB
Frequency Range	75-4000 Hz	1500-18000 Hz
Voice Coil Diameter	65 mm (2.56 in)	25 mm
Winding Material	Al	Al
Former Material	Glass Fiber	Kapton
Winding Depth	12.5 mm (0.49 in)	1.7 mm
Magnetic Gap Depth	8 mm (0.31 in)	2 mm
Flux Density	1 T	1.3 T
Min. Cross. Freq.	-	1.7 kHz
Dispersion Angle	-	90°
Diaphragm Material	-	Ketone Polymer
Diaphragm Shape	-	Dome
Magnet	Ferrite Ring	-
Basket Material	Aluminum	-
Demodulation	No	-
Cone Surround	Triple Roll	-
NET Air Volume filled by Loudspeaker	0.96 dm^3 (0.034 ft^3)	-
Spider Profile	1x constant height waves	-

{ LF }
