Beyma 15LEX1000Fe 15" 1000W 8Ohm
KEY FEATURES
- High power handling and low distortion 15” subwoofer
- Exclusive Malt Cross® Technology Cooling System
- Low power compression losses
- High sensitivity: 97 dB (1W / 1m)
- FEA optimized neodymium magnetic circuit
- Ultra low air noise
- Optimized linear behaviour
- Waterproof cone with treatment for both sides
- 3.5" DUO in/out copper voice coil
- Extended controlled displacement: Xmax ± 11 mm
- 51 mm peak-to-peak excursion before damage
- Optimized for direct radiation and band-pass subwoofer applications
This is NOT a stock item, we can usually order this in and have stock within 40-44 working days. If you require this item urgently, please contact a member of staff to confirm availability.
TECHNICAL SPECIFICATIONS
- Nominal impedance 8 Ohm
- Power capacity 1000 W AES
- Nominal diameter 380 mm 15 in
- Sensitivity 97 dB 1 W @ 1 m @ ZN
- Minimum impedance 7.4 ohm
- Frequency range 40-1000 Hz
- Program power 2000 W
- Recommended enclosure volume 115 l
- Voice coil diameter 88.9 mm 3.5 in
- BL factor 23.2 N/A
- Moving mass 0.142 kg
- Winding length 27 mm
- Air gap height 12 mm
- Xdamage pp 51 mm
PARAMETERS THIELE & SMALL
- Fs 41 Hz
- Re 5.4 ohm
- Qms 5.1
- Qes 0.37
- Qts 0.34
- Vas 116 l
- Cms 106 µm / N
- Rms 7.2 kg/s
- Efficiency % 2.1
- Sd 0.088 m²
- Xmax 11 mm
- Vd 968 cm³
- Le @1 kHz 1.7 mH
CONSTRUCTION DETAILS
- Depth 182 mm 7.2 in
- Net weight 11 kg 24.2 lb
- Total weight 12 kg 26.4 lb
- Magnet Ferrite
